Electrical Panel Hole Lockout – Circular Red

Code:ES-EPHOL-CR

Electrical Panel Hole Lockout made of ABS material, dedicated to locking racking in-out points of circuit breakers and similar devices.

  • Versatile installation options: riveting, screws, or double-sided tapes.
  • Designed to lock switches recessed inside a plane surface.
  • Available in both Red and Yellow colours.
Categories:

100000 in stock

Add To Quote

Product Description

  • Lockout device is made of ABS material and is attached with a rivet for secure installation.
  • This round-shaped lockout device is designed to lock the racking in-out point of air circuit breakers, vacuumed circuit breakers, and other similar devices, preventing unauthorized operation.
  • It is also suitable for locking switches that are recessed inside a plane surface.
  • The lockout can be easily rotated in any direction and has three holes on the bottom base for fixing it with screws or rivets.
  • Alternatively, it can be installed using strong double-sided tapes.
  • The lockout has an outer diameter of 46 mm, inner diameter of 32 mm, lower cover circle side wall thickness of 7 mm, overall thickness of 8 mm (with upper part thickness of 3 mm and lower part thickness of 5 mm), and a locking hole diameter of 1 mm.
  • Available in Red and Yellow colours.
